Triax Digital Freeview Aerial High Gain Unix 52 Element Wide Band

TRIAX UNIX aerials have been designed for UHF-reception and are available in a 52 element version for channel groups as well as wideband. With their high gain and excellent front to back ratios these aerials ensure superior TV reception. The aerials have been designed to ensure optimum reception even under difficult conditions.

Easy and uncomplicated mounting is ensured by the snap-lock dipole house made of UV-resistant plastic. The balun with capacitive signal transfer from the dipole ensures matching adjustment with lower insertion loss. At the same time galvanic corrosion between the different materials in contact with each other is avoided. The aerials are made of salt water resistant aluminium, ensuring long service life.

Performance certified to CAI Aerial Benchmark Standard 2. Suitable for poorer reception areas or loft mounting in medium reception areas for all UK transmitters.



Number of Elements: 52
Gain: 14.5dB
Front/Back: >27dB
Beamwidth: +/- 15 degrees
Windload (N): 96
Weight (kg): 1.63
Size (mm): 1297 x 500mm

Technical specifications

CAI Benchmark Standard 2
Certificate Number CAI/AB 008 (4th issue)
Anti-Ghost Performance

Band Wideband
Band UHF
Channels 21-69
Elements 52
Gain 14.5 dB
Front To Back Ratio >27 dB
Beam Width Hor +/-15 Degrees

Mechanical specifications
Windload 96 N
Weight 1.63 kg
Dimensions lxwxh 1297 x 500 mm
